input voltage

100V~240V AC, 50/60Hz

Rated power

600W

Light source specification

Power 380W Color Temperature 7000K

Rated life 20000 hours

colour

A color palette, each consisting of 14 color plates plus white light; a seven-color film.

pattern

17 pattern effects, 4 rotation pattern effects

Prism

Six prisms have free superposition effect

Soft mirror

Flexible 0-100% Linear Adjustment

focusing

X-ray focusing of DM

Dimming

0-100% linear regulation

aperture

5-100% linear regulation

Strobe

Electronic stroboscopic, 0.3-25 times per second

Rotation angle

540 degrees in horizontal direction and 270 degrees in vertical direction; with automatic return function

Beam angle

The beam angle can be adjusted linearly from 2 to 10 with 16 Bit precision adjustment and automatic focusing function.

control mode

International Standard DMX512 Signal, 3-core, 5-core DMX512 Interface

RDM Control Protocol, Network Control Protocol

Standard mode 24 channels

Master-slave synchronous control mode, stand-alone mode, self-check mode, other functions

Pure color touch screen, bilingual menu in Chinese and English, brightness and contrast can be adjusted, operation panel can be set without power supply, easy to maintain modular structure.

Shell and Protection Level

High temperature resistant engineering plastics, protection grade IP20

Net weight

18kg

Packing volume

450mm*480mm*550mm

The relevant information in this website is for reference only, and all products are subject to the physical object.

If there is any change without notice, Omar lighting reserves the right of final interpretation.
